Input Voltage (V) | 3 Phase, 50/60 Hz, 380 V |
---|---|
Installed Power (kVa) | 15 |
Fuse (delayed action) (A) | 42 |
Open Circuit Voltage (V) | 38 |
Current Range (A) | 5-300 |
Duty Cycle(40°) %100 - %60 - %35 | 180 / 230 / 300 |
Standards | EN 60974-1 / EN 60974-10 |
Protection Class (IP) | 23 |
Insulation Class | H |
Dimensions (L*W*H) (mm) | 680 / 510 / 460 |
Weight (kg) | 101 |
Order Code | Product Name | Optional / Standard |
---|---|---|
3000900015 | This Order Code Covers The Welding Machine and AII of The Equipments | Standard |
3020900105 | RKM 350 | Standard |
2020900647 | Welding Pliers | Standard |
2020900648 | Grounding Pliers | Standard |
6051900088 | GeKa WP 26 Air-Cooled TIG Torch, 4mt | Optional |
