Submerged Arc Welding Machine - Power Saw 1000 AC DC TANDEM
Usage Areas
- Shipyards.
- Pipelines.
- Pressure vessel manufacturers
- Boiler manufacturers.
- Steel structure manufaturers.
Product Features
- High speed DSP control system realizes precise digital control during welding, and improve welding seam formation.
- Controllable AC square waveform output [AC frequency, duty cycle, DC bias] can control the penetration and deposition rate of welding seam.
- Perfect parameters setting of arc starting and stopping solves problems of low arc starting success rate and large crater of arc stopping.
- CC and CV modes
- Synergic operation of twin-wire tandem system
- Polarity can be swithed easily with no wiring change DC and AC outputs, control at will
- Independent air duct design
- 100% duty cycle
- Secondary inverter design, energy saving
Technicial Specifications
| Input Voltage | Isolation Class | Protection Class | Standards | Welding Current Range | No Load Voltage | Power Cons | Dimensions (DxWxH) (mm) | Weight (kg) | Duty Cycle(40°) %100 | Input Current (A) |
|---|---|---|---|---|---|---|---|---|---|---|
| 3 phase, AC380V/400V±10%, 50Hz | H | IP 23 S | EN 60974-1 / EN 60974-10 | 60-1000 | 90 | 55 | 1040×500×720 | 165 | 1000 | 82/78 |
Standard & Optional Equipments
| Order Code | Product Name |
|---|---|
| 3021000143 | This order code covers the welding machine and all of the equipments |
| 1021000113 | POWER SAW 1000 AC/DC POWER SOURCE |
| 1021000063 | POWER SAW 1000 DC POWER SOURCE |
| 1021000116 | TANDEM |
| 2020900686 | Pliers Set |
