Submerged Arc Welding Machine - PoWer SAW 1250
Standards
| Extra Functions | - Hot Start - Arc Force - Wire diameter selection - CC / CV selection - Inductance setting |
|---|
Current Type
- DC
Symbols
Features and Applications
- Especially designed for use under heavy working conditions
- Very good welding performance with tine adjustment control
- • Suitable for long working conditions with %100 duty cycle
- Digital current and voltage setting display
- Suitable to work under ± %10 voltage fluctuations and constant
- Suitable for very long welding seams and very thick workpieces.
- Embedded expert program with 10 sets of complete welding parameters
- Uninfluenced by input voltage fluctation
- • Digital communication between tractor and welder
- 3 and 4 wheeled tractor unit (optional)
- • Flux collecting unit
- The slides have the ability to move horziontally and vertically
- Smart fan feature greatly expands working life
- Self-diagnostic function with error code display
- Electro slag welding facility
MODE
- - LIFT-TIG, MMA Welding, MIG Welding Mode (CV)
Technicial Specifications
| Input Voltage | Power Cons | Delayed Fuse | No Load Voltage | Welding Current Range | Duty Cycle(40°) %100 | Standards | Standards | Protection Class | Isolation Class | Dimensions (DxWxH) (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 Phase, 50/60 Hz, 380 V ±%20 | 75 | 115 | 92 | 60-1250 | 1250 | EN 60974-1 | EN 60974-5 / EN 60974-10 | 23 S | H | 788 x 366 x 815 | 105 |
Standard & Optional Equipments
| Order Code | Product Name |
|---|---|
| 3021000100 | This Order Code Covers The Welding Machine and AII of The Equipments |
| 1021000064 | PoWer SAW 1250 |
| 1020900004 | Tractor |
| 1020900005 | Tractor (optional) |
| 2020900686 | Pliers Set |
