PoWer MIG 555-S
Features and Applications
- Designed for heavy industrial use
- Multi proses
- Robust communication protocols
- Thanks to its tunnel design: Offers increased reliability in dusty environments
- Outstanding welding beams
- Low spatter superior welding performance
Usage Areas
- Maintenance and Repair Applications
- Construction
- Pipe Lines
- Shipyards
- Energy Plants
Technicial Specifications
| Input Voltage | Insulation Class | Protection Class | Standards | No Load Voltage | Delayed Fuse | Weight (kg) | Output Voltage Range | Installed Power | Current Range | Dimensions ((L*W*H) | Duty Cycle at (40°C) - %15 - %60 - %100 | Wire diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 Phase, 50/60 Hz, 400 V ±%10 | H | IP 21S | EN IEC 60974-1 / EN IEC 60974-10 | 67 V | 50 A | 115 kg | 17–40 V | 25 kW | 40–500 A | 980 x 585 x 1350 mm (a x b x h) | (40°C) %100: 400 A %60: 500 A | 0,8 / 1,0 / 1,2 / 1,6 mm |
