Welding Machine - PoWer MIG 630
Features and Applications
- Long-term operating performance with 630 A duty cycle at 100%
- Provides excellent arc performance and energy saving with inverter technology
- With its easy-to-use panel, process selections can be adjusted with just one button.
- Possibility of precise current-voltage adjustment with digital display indicator
- It is suitable for using 0.8 - 2.8 mm diameter welding wires in solid and flux cored wires.
- Welding parameters can be adjusted instantaneously on the wire feeder.
- Ease of access to difficult places with the portable wire feeder unit
- Easy to use
- Durable design with metal body against impacts and heavy working conditions
Technicial Specifications
| Input Voltage | Isolation Class | Protection Class | Standards | Welding Current Range | No Load Voltage | Delayed Fuse | Power Cons | Dimensions (DxWxH) (mm) | Weight (kg) | Duty Cycle(40°) %100 | Output Voltage Range | Wire Dimensions (mm) Power |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50-60Hz 380±%20 | H | IP 21 S | EN IEC 60974-1 / EN IEC 60974-10 | 60-630 | 91 | 51 | 33 | 800 x 720 x 310 | 133 | 630 | 17-44 | 0,8-2,8 |
Standard & Optional Equipments
| Order Code | Product Name |
|---|---|
| 3021000124 | This order code covers the welding machine and all of the equipments (Water cooled) |
| 1051300003 | Pressure Regulator (Ar) |
| 1051300003 | Pressure Regulator (Co2) |
| 2020900660 | Pliers Set |
| 2020900258 | (Water cooled) |
| 1051900012 | Water Cooled |
| 1020900009 | Wire Feeder |
| 1021000102 | PoWer MIG 630 |
Areas of Use
- Production
- Construction
- Pipe Lines
- Shipyards
- Maintenance and Repair Applications
- Energy Plants
