TIG Welding Machine - PoWer TIG 202 DC Pulse
Current Type
- DC
Features and Applications
- Standard equipped with pulse mode integrated into the control with available “EASY PULSE” facility
- Precise and efficient TIG arc striking by high frequency
- Steady, easily targeted arc makes welding easy
- Low energy consumption and high efficiency
- Automatic compensation tor mains voltage fluctuations within + %15 -%20
- Digital control of all the welding parameters with the ability to store 9 personalised programs
- High performance on thin metal sheets
- Cycle and Pulse Functions improve welding productivity
- Perform very well in MMA welding, single - Phase network
- Light weight and a compact size give better reach
Technicial Specifications
| . | TIG | MMA |
|---|---|---|
| Input Voltage (V) | 1 Phase 50/60 Hz, 230 V | 1 Phase 50/60 Hz, 230 V |
| Installed Power (kVA) | 8.5 | 9.0 |
| Fuse (delayed action) (A) | 20 | 20 |
| Open Circuit Voltage (V) | 88 | 88 |
| Current Range (A) | 5-200 | 5-160 |
| Duty Cycle at (40°C) %100 | 120 | 110 |
| Duty Cycle at (40°C) %60 | 140 | 130 |
| Duty Cycle at (40°C) %25 | 200 | 160 (%30) |
| Standards | EN 60974-1 / EN 60974-3 / EN 60974-10 | EN 60974-1 / EN 60974-3 / EN 60974-10 |
| Protection Class (IP) | 23 S | 23 S |
| Insulation Class | F | F |
| Dimensions (L*W*H) (mm) | 390 / 135 / 300 | 390 / 135 / 300 |
| Weight (kg) | 7.5 | 7.5 |
Standard & Optional Equipments
| Order Code | Product Name | Optional / Standard |
|---|---|---|
| 3021000001 | This Order Code Covers The Welding Machine and AII of The Equipments | Standard |
| 1021000001 | PoWer TIG 202 DC Pulse | Standard |
| 2020900723 | Welding Pliers | Standard |
| 6051900083 | GeKa WP 26 Air-Cooled TIG Torch 4mt | Standard |
| 1051300003 | Argon Regulator | Standard |
