PoWerTech 405 Pulse
Symbols
Features and Applications
- Digital control of the welding parameters with synergic curves preset according to used type of material, gas and wire diameter
- Multiprocess power sources: MMA/LIFT TIG / MIG/MAG Synergic & Manual-Pulse and Double Pulse
- Synergic multiprocess inverter compact power equipment
- Ability to store personalized welding parameters up to 99 JOBS
- “Smart PROGRAM” key for quickly selecting any program
- Feeding mechanism with 4 rolls of large diameter for a precise and constant wire driving
- Double groove rolls replaceable without any tool
- “Energy saving” function to operate the power source cooling fan and torch water cooling only when necessary
- Excellent arc striking always precise and efficient
- Ability to partially or totally lock the equipment with access key by password
- Reduced energy consumption
- Trouble shooting auto-diagnosis feature
- Initial and final crater control
- VRD – Voltage Reduction Device,
Warranty
- GEDİK Welding provides full support for after sales services. 1 year warranty.
Technicial Specifications
| Input Voltage (V) | 3 Phase, 50/60 Hz, 400 ± 20 V |
|---|---|
| Installed Power (kVa) | 23.7 |
| Fuse (delayed action) (A) | 32 |
| Open Circuit Voltage (V) | 63 |
| Current Range (A) | 10-400 |
| Standards | EN 60974-1 / EN 60974-5 / EN 60974-10 |
| Duty Cycle(40°) %100 - %60 - %40 | 300 / 350 / 400 |
| Usable Wire Diameters | 0.6 - 1.2 |
| Protection Class (IP) | 23 S |
| Insulation Class | H |
| Dimensions (L*W*H) (mm) | 660 / 290 / 515 |
| Weight (kg) | 43 |
